Virtual Desktop Switcher

A KDE Plasma 5 widget that displays the current virtual desktop name and provides a visual overview of all desktops with real window positions.

Features

• Real-time desktop name in panel - Shows active virtual desktop name
• Hover to open - Popup appears automatically when hovering (80ms delay)
• Real window geometry - Windows displayed in actual positions using native KDE pager API
• Window icons - Application icons shown inside window previews
• Proper aspect ratio - Desktop previews match your screen proportions
• Grid layout - Automatically arranges desktops in optimal columns/rows
• Desktop management:
  • Click to switch desktop
  • Right-click to rename or delete
  • Add new desktops with "Add" button
  • Scroll wheel to cycle through desktops
• High performance - Uses native PagerModel instead of shell commands

Screenshots

The widget shows a grid of desktop previews with:

• Window outlines in real positions
• Application icons inside windows
• Desktop number and name badge
• Active desktop highlighted

Installation

Manual Installation

# Clone the repository
git clone https://github.com/andresgarcia0313/plasma-virtual-desktop-switcher.git

# Copy to Plasma plasmoids directory
cp -r plasma-virtual-desktop-switcher ~/.local/share/plasma/plasmoids/org.kde.virtualdesktopswitcher

# Restart Plasma
kquitapp5 plasmashell && kstart5 plasmashell

Add to Panel

1. Right-click on your panel → Add Widgets
2. Search for "Virtual Desktop Switcher"
3. Drag to your panel

Configuration

Right-click on the widget → Configure Virtual Desktop Switcher

Option	Description
Show window previews	Display window outlines inside desktop previews
Show window icons	Display application icons on window rectangles
Preview size	Adjust the size of preview area (40-150px)

Usage

Action	Result
Hover	Opens desktop overview popup
Click on desktop	Switches to that desktop
Right-click on desktop	Context menu (Rename, Delete)
Scroll wheel	Cycles through desktops
Add button	Creates new virtual desktop

Requirements

• KDE Plasma 5.27 or later
• KWin window manager
• Qt 5.15+

Technical Details

Architecture

The widget uses the native KDE pager plugin (org.kde.plasma.private.pager) which provides:

• PagerModel - Virtual desktop model with real-time updates
• TasksModel - Window information including geometry
• pagerItemSize - Screen dimensions for aspect ratio

Key Files

org.kde.virtualdesktopswitcher/
├── metadata.desktop          # Plugin metadata
├── contents/
│   ├── config/
│   │   ├── main.xml         # Configuration schema
│   │   └── config.qml       # Config page registration
│   └── ui/
│       ├── main.qml         # Main widget code
│       └── configGeneral.qml # Settings UI

QML Imports Used

import org.kde.plasma.plasmoid 2.0
import org.kde.plasma.core 2.0 as PlasmaCore
import org.kde.plasma.components 3.0 as PlasmaComponents
import org.kde.plasma.private.pager 2.0  // Native pager API

Window Geometry Scaling

Windows are scaled from screen coordinates to preview size:

readonly property real scaleX: deskW / pagerModel.pagerItemSize.width
readonly property real scaleY: deskH / pagerModel.pagerItemSize.height

x: Math.round(model.Geometry.x * scaleX)
y: Math.round(model.Geometry.y * scaleY)

Development

Testing Changes

# Edit files in
~/.local/share/plasma/plasmoids/org.kde.virtualdesktopswitcher/

# Restart Plasma to see changes
kquitapp5 plasmashell && kstart5 plasmashell

Debugging

# View Plasma logs
journalctl -f | grep -i plasma

# Check QML errors
QT_LOGGING_RULES="qml.debug=true" plasmashell

KWin D-Bus API

# List virtual desktops
gdbus call --session --dest org.kde.KWin \
  --object-path /VirtualDesktopManager \
  --method org.freedesktop.DBus.Properties.Get \
  org.kde.KWin.VirtualDesktopManager desktops

# Get current desktop
qdbus org.kde.KWin /VirtualDesktopManager current

# Rename desktop
qdbus org.kde.KWin /VirtualDesktopManager setDesktopName '<id>' 'New Name'

# Create desktop
qdbus org.kde.KWin /VirtualDesktopManager createDesktop <position> 'Name'

# Remove desktop
qdbus org.kde.KWin /VirtualDesktopManager removeDesktop '<id>'

Contributing

Contributions are welcome! Please:

1. Fork the repository
2. Create a feature branch
3. Make your changes
4. Test thoroughly
5. Submit a pull request

License

This project is licensed under the GPL-3.0 License - see the LICENSE file for details.

Credits

• Uses KDE Plasma's native pager plugin for window geometry
• Inspired by the official KDE Pager widget

Author

Andres Garcia - GitHub
